Asrock 90-MXBJY0-A0IAYZ B650E STEEL LEGEND Sc-AM5 DDR5 7600Mhz M2 Wi-Fi 6E ATX AMD Anakart

  • Unique Feature
    Superb Productivity
    - PCIe Gen5 (Graphics, M.2)
    - Dual Channel DDR5
    Rock-Solid Durability
    - Server-Grade Low-Loss PCB
    - 16+2+1 Power Phase, 60A SPS
    - Flexible Integrated I/O Shield
    - Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors)
    Ultrafast Connectivity
    - 2.5G LAN,
    802.11ax Wi-Fi 6EModule
    EZ Update
    - BIOS Flashback Button
    - ASRock Auto Driver Installer
    EZ Troubleshooter
    - ASRock Post Status Checker
  • CPU
    - Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors*

    *The availability of expansion slots may vary by CPU. Please refer to PCIe/M.2 Bandwidth Table for details.
  • Chipset
    - AMD B650
  • Memory
    - Dual Channel DDR5 Memory Technology
    - 4 x DDR5 DIMM Slots
    - Supports DDR5 ECC/non-ECC, un-buffered memory up to 7600+(OC)*
    - Max. capacity of system memory: 192GB
    - Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules

    *Please refer to Memory Support List for more information.
  • BIOS
    - 256Mb AMI UEFI Legal BIOS with GUI support
  • Graphics
    Integrated AMD RDNA™ graphics (Actual support may vary by CPU)
    - 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
    - 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 4K 120Hz
  • Audio
    - 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
    - Nahimic Audio
  • LAN
    - 2.5 Gigabit LAN 10/100/1000/2500 Mb/s
    - Dragon RTL8125BG
    - Supports Dragon 2.5G LAN Software
    - Smart Auto Adjust Bandwidth Control
    - Visual User Friendly UI
    - Visual Network Usage Statistics
    - Optimized Default Setting for Game, Browser, and Streaming Modes
    - User Customized Priority Control
    • Wireless LAN
      - 802.11ax Wi-Fi 6E Module
      - Supports IEEE 802.11a/b/g/n/ac/ax
      - Supports Dual-Band 2x2 with extended 6GHz band support*
      - 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology
      - Supports Bluetooth 5.2 + High speed class II
      - Supports MU-MIMO

      *Wi-Fi 6E (6GHz band) will be supported by Microsoft Windows® 11. The availability will depend on the different regulation status of each country and region. It will be activated (for supported countries) through Windows® Update and software updates once available.
      A 6GHz compatible router is required for 6E functionality.
    • Slots
      CPU:
      - 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*
      - 1 x PCIe 3.0 x16 Slot (PCIE2), supports x4 mode*
      Chipset:
      - 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module

      - Supports AMD CrossFire™
      - 15μ Gold Contact in VGA PCIe Slot (PCIE1)

      *Supports NVMe SSD as boot disks
    • Storage
      CPU:
      - 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen5x4 (128 Gb/s) mode*
      Chipset:
      - 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode*
      - 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2230/2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode*
      - 2 x SATA3 6.0 Gb/s Connectors


      *Supports NVMe SSD as boot disks
      Supports ASRock U.2 Kit
    • RAID
      - Supports RAID 0 and RAID 1 for SATA storage devices
      - Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices*

      *Requires additional M.2 NVMe expansion cards to support RAID 10
    • USB
      - 1 x USB 3.2 Gen2x2 Type-C (Front)
      - 1 x USB 3.2 Gen2 Type-C (Rear)
      - 1 x USB 3.2 Gen2 Type-A (Rear)
      - 8 x USB 3.2 Gen1 (4 Rear, 4 Front)
      - 6 x USB 2.0 (2 Rear, 4 Front)

      *All USB ports support ESD Protection
    • Connector
      - 1 x SPI TPM Header
      - 1 x Power LED and Speaker Header
      - 1 x RGB LED Header*
      - 3 x Addressable LED Headers**
      - 1 x CPU Fan Connector (4-pin)
      Diğer Özellikler
      Stok Kodu90-MXBJY0-A0IAYZ
      MarkaASROCK
      Stok DurumuBu ürün geçici olarak temin edilememektedir.
      4710483940866
