2-Port USB-C Gen 1 Dock Switch with Power Pass-through
- Allows a USB-C laptop and an Android Smartphone to share one HDMI monitor and all connected USB peripherals*
- Provides USB Power Delivery 3.0 for laptop charging up to 85W (additional USB-C Power Adapter needed)**
- Supports 4K resolutions – up to 3840 x 2160 @ 30Hz
- Supports Samsung DeX mode or Huawei Desktop mode***
- Video DynaSync – allows EDID and HDCP monitors and computers to function flawlessly, and provides fast switching such as continuous real-time switching
- Switch device via remote port selector by pressing a button
- Plug and play – no drivers or external power adapter needed
*For video output to work through a USB-C port, it must support DP Alt Mode.
**For device charging, a Limited Power Source (LPS) certified USB-C PD Power Adapter over 65Watt is recommended. The minimum system power requirement for basic USB functions and video output should be at least 5V, 3A.
***Compatible with smartphones launched in 2018 or later that feature video output DP ALT mode over USB-C. For a list of supporting mobile device, refer to US3310's user manual
- 1x US3310 2-Port USB-C Gen 1 Dock Switch with Power Pass-through
- 2x USB-C Cables
- 1x Remote Port Selector
- 1x User Instructions
Computer Connections | 2 |
Connectors |
Computer | USB 3.2 Gen 1 Type-C Port 1 (Laptop) USB 3.2 Gen 1 Type-C Port 2 (Android : Samsung Dex or Huawei Desktop mode) |
Device | 2 x USB 3.2 Gen 2 Type-A Female |
Video Output | 1 x HDMI Female |
Power | 1 x USB-C DC-in Female*
Port 1 : Supports USB-C PD laptop charging at 5V, 9V, 15V, 20V output* Port 2 : Supports max. 5V, 2A output
*Supports maximum 100W USB-C PD power adapter input. *For device charging, a Limited Power Source (LPS) certi?ed USB-C PD Power Adapter over 65 Watt is recommended. The minimum system power requirement for basic USB functions and video output should be at least 5V, 3A. |
Port Selection |
Input | Remote port selector |
Video Resolution | 3840 x 2160@30hz |
Power Consumption | DC5V:1.24W:406BTU |
LEDs |
Selected | 2 (White) |
Environmental |
Operating Temperature | 0–40°C |
Storage Temperature | -20–60°C |
Humidity | 0–80% RH, Non-condensing |
Physical Properties |
Housing | Aluminum |
Weight | 0.33 kg ( 0.73 lb ) |
Dimensions (L x W x H) | 14.30 x 11.90 x 2.38 cm (5.63 x 4.69 x 0.94 in.) |
Diğer Özellikler |
Stok Kodu | ATEN-US3310 |
Marka | ATEN |
Stok Durumu | Var |
Garanti (Yıl) | 2 |
4719264648991
