Digitus AB 814 4 PC 1 Giriş 4 Çıkış PC VGA Paylaşım Cihazı

PC Paylaşım Cihazı (AT CPU Switch), 4 PC, 1 giriş - 4 çıkış


• Mouse emulation and keyboard emulation for automatic PC boot up.
• Three levels daisy chain cascadable for accessing up to 216 computers.
• Provides serial mouse and keyboard ports.
• Supports SVGA, VGA and Multisync monitors.
• Selects any computer by hot keys, buttons.
• Optional Foot Switch to select any computer.
• Built-in buzzer for switching confirmation.
• Keyboard LED status recorded and restored while switching among computers.
• Auto Scan for monitoring PC periodically



PC Selection	Keyboard / Button / Foot Switch
Keyboard Emulation	PS/2 and PC/AT
Mouse Emulation	Serial Mouse
LEDs	6 Manual / 6 Port Status
Video / VGA Band Width (-3db) MHz	100 MHz
Max VGA Resolution / Vertical Freq. MHz	1024 x 768 / 80
Console Keyboard Connector	5-pin DIN Female
Console Mouse Connector	9-pin D Type Male
VGA Connector Port	15-pin HDB Type Male
Enclosure	Metal
Weight	2800g or 7.5 pounds
Dimensions (L x W x H)	254 x 180 x 82 (mm)
Scan Interval	3, 10, 20, 40 seconds
Optional Power Adapter	230AC, Europe Plug
Standard Power Adapter	120AC, US standard
