Planet PL-GS-4210-24T2S 24 Port Gigabit 2 Port SFP Yönetilebilir Rack Mount Switch
Para_Puan : 35.032
1
Yönetilebilir Gigabit Switch (Managed Gigabit Switch)
24-port 10/100/1000Base-T
2 x 100/1000BASE-X mini-GBIC/SFP yuva
1 x Konsol port
Reset düğmesi (sistem fabrika ayarlarına dönmek için)
Physical Port
Switching
Layer 2 Features
Quality of Service
Multicast
Security
Management
24-port 10/100/1000Base-T
2 x 100/1000BASE-X mini-GBIC/SFP yuva
1 x Konsol port
Reset düğmesi (sistem fabrika ayarlarına dönmek için)
Physical Port
- 24-port 10/100/1000BASE-T Gigabit RJ45 copper
- 2 100/1000BASE-X mini-GBIC/SFP slots
- RJ45 console interface for switch basic management and setup
- Reset button for system factory default
Switching
- Hardware based 10/100Mbps, half / full duplex and 1000Mbps full duplex mode, flow control and auto-negotiation and auto MDI/MDI-X
- Features Store-and-Forward mode with wire-speed filtering and forwarding rates
- IEEE 802.3x flow control for full duplex operation and back pressure for half duplex operation
- 9K Jumbo frame
- Automatic address learning and address aging
- Supports CSMA/CD protocol
Layer 2 Features
- - IEEE 802.1Q tagged VLAN
- - Provider Bridging (VLAN Q-in-Q) support (IEEE 802.1ad)
- - Protocol VLAN
- - Voice VLAN
- - Private VLAN (Protected port)
- - Management VLAN
- - GVRP
- - STP (Spanning Tree Protocol)
- - RSTP (Rapid Spanning Tree Protocol)
- - MSTP (Multiple Spanning Tree Protocol)
- - STP BPDU Guard, BPDU Filtering and BPDU Forwarding
- Supports VLAN
- Supports Spanning Tree Protocol
- Supports Link Aggregation
- - IEEE 802.3ad Link Aggregation Control Protocol (LACP)
- - Cisco ether-channel (Static Trunk)
- - Maximum 8 trunk groups, up to 8 ports per trunk group
- Provides port mirror (many-to-1)
- Loop protection to avoid broadcast loops
Quality of Service
- Ingress / Egress Rate Limit per port bandwidth control
- Traffic classification
- IEEE 802.1p CoS
- DSCP / IP Precedence of IPv4 / IPv6 packets
- Strict priority and Weighted Round Robin (WRR) CoS policies
Multicast
- Supports IPv4 IGMP snooping v2 and v3
- Supports IPv6 MLD snooping v1, v2
- IGMP querier mode support
- IGMP snooping port filtering
- MLD snooping port filtering
Security
- - Broadcast / Unknown-Unicast / Unknown-Multicast
- - IEEE 802.1X port-based network access authentication
- - Built-in RADIUS client to co-operate with the RADIUS servers
- - DHCP Option 82
- - RADIUS / TACACS+ authentication
- - IPv4 / IPv6 IP-based ACL
- - IPv4 / IPv6 IP-based ACE
- - MAC-based ACL
- - MAC-based ACE
- - Static MAC
- - MAC Filtering
- Storm Control support
- Authentication
- Access Control List
- MAC Security
- Port security for source MAC address entries filtering
- DHCP snooping to filter distrusted DHCP messages
- Dynamic ARP inspection discards ARP packets with invalid MAC address to IP address binding
- IP source guard prevents IP spoofing attacks
- DoS attack prevention
Management
- - Local Command Line Interface
- - IPv4 / IPv6 Web switch management
- - Telnet Command Line Interface
- - SNMP v1, v2c and v3
- - HTTPs secure access
- - Firmware upload / download via HTTP / TFTP
- - Configuration upload / download through HTTP / TFTP
- - Hardware reset button for system reset to factory default
- IPv4 and IPv6 dual stack management
- Switch Management Interface
- Built-in Trivial File Transfer Protocol (TFTP) client
- Static and DHCP for IP address assignment
- System Maintenance
- SNTP Network Time Protocol
- Cable diagnostics
- Link Layer Discovery Protocol (LLDP) Protocol and LLDP-MED
- SNMP trap for interface Link Up and Link Down notification
- Event message logging to remote Syslog server
- Four RMON groups (history, statistics, alarms and events)
- PLANET Smart Discovery Utility
| Hardware Specifications | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Copper Ports | 24 x 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| SFP/mini-GBIC Slots | 2 100/1000BASE-X SFP interfaces, supporting 100/1000Mbps dual mode | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Console | 1 x RS232-to-RJ45 serial port (115200, 8, N, 1) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Reset Button | System factory default | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Switch Architecture | Store-and-Forward | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Switch Fabric | 52Gbps / non-blocking | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Switch Throughput@64 bytes | 38.6Mpps @64 bytes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| MAC Address Table | 8K entries | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Shared Data Buffer | 4.1 megabits | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Flow Control | IEEE 802.3x pause frame for full-duplex Back pressure for half-duplex | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Jumbo Frame | 9216 bytes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Reset Button | > 5 sec: Factory default | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| LED | System: Power (Green) 10/100/1000T RJ45 Interfaces (Port 1 to Port 24): 1000 LNK / ACT (
