    Planet PL-GSD-805 8 Port 10/100/1000Base-T Gigabit Masaüstü Ethernet Switch

    Planet PL-GSD-805 8 Port 10/100/1000Base-T Gigabit Masaüstü Ethernet Switch Planet PL-GSD-805 8 Port 10/100/1000Base-T Gigabit Masaüstü Ethernet Switch Planet PL-GSD-805 8 Port 10/100/1000Base-T Gigabit Masaüstü Ethernet Switch
    Görsel 1
    Görsel 2
    Görsel 3
    Para_Puan : 20.780
    Fiyat:
    2.493,59 TL
    Aynı Gün Kargo Kargo Bedava

    Ürüne Oy Verin

    Satıcıya Danış

    Yönetilemeyen Switch 8-Port 10/100/1000BASE-T


    RJ45 Interface
    • 8 10/100/1000Mbps Gigabit Ethernet ports
    • Complies with IEEE 802.3, 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T
    • Supports auto MDI/MDI-X function

    Switching

    • Hardware-based 10/100Mbps in half / full duplex mode and 1000Mbps in full duplex mode, flow control, and auto-negotiation
    • Features Store-and-Forward mode with wire-speed filtering and forwarding rates
    • IEEE 802.3x flow control for full duplex operation and backpressure for half duplex operation
    • Integrated address look-up engine, supporting 8K absolute MAC addresses
    • 9K jumbo packet size
    • Automatic address learning and address aging
    • Supports VLAN isolation mode
    • Supports CSMA/CD protocol

    Hardware

    • Metal housing, desktop size and wall-mount design
    • LED indicators for system power, Link / Act port
    • Internal power adapter 100-240V AC, 50/60Hz, 0.2A
    • FCC, CE Class B compliant

    Hardware Specifications
    Network Connector8-Port RJ45 for 10/100/1000BASE-T, auto MDI/MDIX
    LED DisplaySystem: Power(Green)
    Per port: 10/100/1000 LNK/ACT(Green)
    Switch ArchitectureStore and Forward switch architecture
    MAC Address Table8K MAC address table with auto learning function
    Packet Buffer1Mbit
    Switch Fabric16Gbps
    Switch Throughput11.9Mpps @64 bytes
    Jumbo Packet9216 bytes
    Flow ControlBack pressure for half-duplex. IEEE 802.3x pause frame for full-duplex
    Power RequirementsInternal power 100-240V AC, 50/60Hz, 0.2A
    Power ConsumptionMax. 2.4 watts/8.1 BTU
    Dimensions (W x D x H)168 x 93 x 32mm
    ESD ProtectionContact Discharge 4KV DC
    Air Discharge 6KV DC
    EFT ProtectionESD (Ethernet): 2KV
    Surge (EFT for power): 4KV
    Surge ProtectionDifferent module ±1.5KV
    Common mode ±2KV
    Electrostatic Standard±2KV
    Weight428g
    Standard Conformance
    EMI SafetyFCC Class B, CE
    Standard ComplianceIEEE 802.3?? Ethernet
    IEEE 802.3u??Fast Ethernet
    IEEE 802.3ab? Gigabit Ethernet
    IEEE 802.3az ?Energy-Efficient Ethernet
    IEEE 802.3x??Flow Control
    Environment
    Operating Environment0 ~ 50 degrees C
    Storage Environment-10 ~ 70 degrees C
    Operating Humidity5 ~ 95%, relative humidity, non-condensing
    Storage Humidity5 ~ 95%, relative humidity, non-condensing


    Diğer Özellikler
    Stok KoduPL-GSD-805
    MarkaPLANET
    Stok DurumuVar
    Garanti (Yıl)2
    4711213684869
