    Planet PL-IGS-12040MT 8 Port 10/100Base-T 4 Port 1000Base SFP Endüstriyel Yönetilebilir Switch

    Görsel 1
    Para_Puan : 135.270
    Fiyat:
    16.232,40 TL
    Havale / EFT:
    15.712,96 TL
    3.030,05 TL'den başlayan taksit seçenekleri için tıklayın.
    1
    Sınırlı Sayıda Kargo Bedava
    Endüstriyel Tip Yönetilebilen Switch (Industrial Managed Switch)
    8-Port 10/100/1000Base-T
    4 x 1000BASE-SX/LX/BX SFP/mini-GBIC yuva (Port-9 ile Port-12 arası), 100Base-FX SFP uyumlu
    IP30, -40~75 Derece C
    1 x Konsol port


    Physical Port
    • 8-Port 10/100/1000BASE-T RJ45 copper
    • 4 100/1000BASE-X mini-GBIC/SFP slots, SFP type auto detection
    • One RJ45 console interface for basic management and setup

    Industrial Case / Installation
    - 12 to 72V DC, redundant power with polarity reverse protect function
    - AC 24V power adapter acceptable
    • IP30 aluminum case protection
    • DIN-rail and wall-mount design
    • Redundant Power Design
    • Supports EFT protection for 6000V DC power and 6000V DC Ethernet ESD protection
    • -40 to 75 degrees C operating temperature

    Digital Input / Digital Output
    • 2 Digital Input (DI)
    • 2 Digital Output (DO)
    • Integrates sensors into auto alarm system
    • Transfers alarm to IP network via email and SNMP trap

    Layer 2 Features
    - Broadcast / Multicast / Unknown Unicast
    - IEEE 802.1Q tagged VLAN
    - Up to 255 VLANs groups, out of 4095 VLAN IDs
    - Provider Bridging (VLAN Q-in-Q) support (IEEE 802.1ad)
    - Private VLAN Edge (PVE)
    - Protocol-based VLAN
    - MAC-based VLAN
    - Voice VLAN
    - STP, IEEE 802.1D Spanning Tree Protocol
    - RSTP, IEEE 802.1w Rapid Spanning Tree Protocol
    - MSTP, IEEE 802.1s Multiple Spanning Tree Protocol by VLAN
    - BPDU Guard
    - 802.3ad Link Aggregation Control Protocol (LACP)
    - Cisco ether-channel (static trunk)
    - Maximum 6 trunk groups, up to 8 ports per trunk group
    - Up to 16Gbps bandwidth (duplex mode)
    • High performance of Store-and-Forward architecture and runt/CRC filtering eliminates erroneous packets to optimize the network bandwidth
    • Storm Control support
    • Supports VLAN
    • Supports Spanning Tree Protocol
    • Supports Link Aggregation
    • Provides port mirror (many-to-1)
    • Port Mirroring of the incoming or outgoing traffic on a particular port
    • Loop protection to avoid broadcast loops
    • Supports E.R.P.S. (Ethernet Ring Protection Switching)
    • IEEE 1588 and Synchronous Ethernet network timing

    Quality of Service
    - IEEE 802.1p CoS
    - IP TOS / DSCP / IP Precedence
    - IP TCP/UDP port number
    - Typical network application
    • Ingress Shaper and Egress Rate Limit per port bandwidth control
    • 8 priority queues on all switch ports
    • Traffic classification
    • Strict priority and Weighted Round Robin (WRR) CoS policies
    • Supports QoS and In/Out bandwidth control on each port
    • Traffic-policing policies on the switch port
    • DSCP remarking

    Multicast
    • Supports IPv4 IGMP Snooping v1, v2 and v3
    • Supports IPv6 MLD Snooping v1 and v2
    • Querier mode support
    • IGMP Snooping port filtering
    • MLD Snooping port filtering
    • MVR (Multicast VLAN Registration)

    Security
    - IEEE 802.1x Port-based / MAC-based network access authentication
    - Built-in RADIUS client to cooperate with the RADIUS servers
    - TACACS+ login users access authentication
    - RADIUS / TACACS+ users access authentication
    - IP-based Access Control List (ACL)
    - MAC-based Access Control List
    • Authentication
    • Access Control List
    • Source MAC / IP address binding
    • DHCP Snooping to filter un-trusted DHCP messages
    • Dynamic ARP Inspection discards ARP packets with invalid MAC address to IP address binding
    • IP Source Guard prevents IP spoofing attacks
    • Auto DoS rule to defend DoS attack
    • IP address access management to prevent unauthorized intruder

    Layer 3 IP Routing Features
    • Supports maximum 32 static routes and route summarization

    Management
    - Console / Telnet Command Line Interface
    - Web switch management
    - SNMP v1, v2c, and v3 switch management
    - SSH / SSL secure access
    - Firmware upload/download via HTTP / TFTP
    - Reset button for system reboot or reset to factory default
    - Dual Images
    - ICMPv6 / ICMPv4 Remote Ping
    - Cable Diagnostic technology provides the mechanism to detect and report potential cabling issues
    • IPv4 and IPv6 dual stack management
    • Switch Management Interfaces
    • IPv6 IP Address / NTP / DNS management
    • Built-in Trivial File Transfer Protocol (TFTP) client
    • BOOTP and DHCP for IP address assignment
    • System Maintenance
    • DHCP Relay and DHCP Option82
    • User Privilege levels control
    • NTP (Network Time Protocol)
    • Link Layer Discovery Protocol (LLDP) and LLDP-MED
    • SFP-DDM (Digital Diagnostic Monitor)
    • Network Diagnostic
    • SMTP / Syslog remote alarm
    • Four RMON groups (history, statistics, alarms and events)
    • SNMP trap for interfacing Link Up and Link Down notification
    • System Log
    • PLANET Smart Discovery Utility for deploy management
    Diğer Özellikler
    Stok KoduPL-IGS-12040MT
    MarkaPLANET
    Stok DurumuVar
    Garanti (Yıl)2
    4711605281010
