    Planet PL-POE-163 Gigabit 1000Mbps 30W High Power Ethernet Injector

    Görsel 1
    Görsel 2
    Görsel 3
    Para_Puan : 12.558
    Fiyat:
    1.507,01 TL
    Havale / EFT:
    1.458,79 TL
    281,31 TL'den başlayan taksit seçenekleri için tıklayın.
    1
    Sınırlı Sayıda Kargo Bedava

    IEEE 802.3at Gigabit High Power over Ethernet Injector (10/100/1000Mbps, Mid-span, 30 Watt)


    Interface
    - 1-port Data + Power output
    - 1-port Data input
    • 2-port RJ45 interfaces
    • 1 AC 100-240V input power socket

    Power over Ethernet
    • 1-port Gigabit High Power over Ethernet Mid-span PSE
    • IEEE 802.3at Power over Ethernet Plus compliant
    • Backward compatible with IEEE 802.3af Power over Ethernet
    • Supports PoE Power up to 30 watts for PoE port
    • Up to 1 IEEE 802.3at device powered
    • Provides DC 53V power over RJ45 Ethernet cable to device with Ethernet port
    • Auto-detection of PoE IEEE 802.3at/af equipment and devices that could be damaged by incorrect installation
    • Remote power feeding up to 100m

    Hardware
    • All-in-one design with internal power supply
    • Compact-size plastic case
    • LED indicators for Power LED and Active LED (PoE ready-in-use)

    Hardware Specifications
    Interface"Data" Input Port: 1 x RJ45 STP
    "PoE (Data + Power)" Output Port: 1 x RJ45 STP
    AC Input Power Socket: 1
    LED IndicatorSystem: Power x 1 (Green)
    PoE Port: Active, PoE ready-in-use x 1 (Green)
    Network Cable10BASE-T: 2-pair UTP Cat. 3, 4, 5, up to 100M (328ft)
    100BASE-TX: 2-pair UTP Cat. 3, 4, 5, up to 100M (328ft)
    1000BASE-T: 2-pair UTP Cat. 5, 5e, 6 up to 100M (328ft)
    EIA/TIA-568 100-ohm STP (100m)
    Data Rate10/100/1000Mbps
    Dimensions (W x D x H)115 x 62.5 x 31 mm
    Weight177g
    Unit Output VoltageDC 53V, 0.6A
    Power Requirements100-240V AC, 50/60Hz, 0.75A
    Power Consumption30 watts max.
    Number of Devices that can be powered1
    Operating Temperature0 ~ 50 degrees C
    Storage Temperature-10 ~ 70 degrees C
    Operating Humidity5 ~ 95%, relative humidity, non-condensing
    Storage Humidity5 ~ 95%, relative humidity, non-condensing
    Power over Ethernet
    PoE StandardIEEE 802.3at Power over Ethernet Plus/PSE
    PoE Power OutputDC 53V/30 watts
    PoE Power Supply TypeMid-span
    Power Pin Assignment4/5(+), 7/8(-)
    Standards Conformance
    Standards ComplianceIEEE 802.3 10BASE-T Ethernet
    IEEE 802.3u 100BASE-TX Fast Ethernet
    IEEE 802.3ab 1000BASE-T Gigabit Ethernet
    IEEE 802.3at High Power over Ethernet Plus
    IEEE 802.3af Power over Ethernet
    Regulatory ComplianceFCC Part 15 Class B, CE

    Diğer Özellikler
    Stok KoduPL-POE-163
    MarkaPLANET
    Stok DurumuVar
    Garanti (Yıl)2
    4711213689345
