      • Planet PL-POE-175-95 10/100/1000Mbps 95W PoE Injector

      Planet PL-POE-175-95 10/100/1000Mbps 95W PoE Injector Planet PL-POE-175-95 10/100/1000Mbps 95W PoE Injector
      Görsel 1
      Görsel 2
      Para_Puan : 45.586
      Fiyat:
      5.470,26 TL
      Havale / EFT:
      5.306,15 TL
      1.021,12 TL'den başlayan taksit seçenekleri için tıklayın.
      1
      Kargo Bedava

      Ürüne Oy Verin

      Satıcıya Danış

      1-Port 10/100/1000Mbps 802.3bt PoE Injector  95 Watt Dahili AC Güç Kaynağı 0-50 derece

      Interface
      • 2 RJ45 interfaces
        • 1-port Data + Power output
        • 1-port Data input
      • 1 AC 100~240V input power socket

      Power over Ethernet
      • Complies with IEEE 802.3at/bt PoE end-span/mid-span PSE
      • Supports PoE power up to 95 watts for PoE port
      • Auto-detection of PoE IEEE 802.3at/bt equipment and devices from being damaged by incorrect installation
      • Monitor the status of the total PoE usage in real time
      • Remote power feeding up to 100m

      Hardware
      • All-in-one compact size design
      • Internal power supply
      • LED indicators for Power LED, PoE Usage LED and 2-/4-pair LED
      • Wall-mount design
      Hardware Specifications
      InterfaceInput Port
      1 x RJ45 STP
      Data In

      Output Port
      1 x RJ45 STP
      PoE (Data + Power) Out

      AC Socket
      1 x AC input socket
      Network CableTwisted-pair cable up to 100 meters (328ft)
      10BASE-T: 4-pair UTP Cat. 3, 4, 5, 5e, 6
      100BASE-TX: 4-pair UTP Cat. 5, 5e, 6
      1000BASE-T: 4-pair UTP Cat. 5e, 6
      LED IndicatorPWR x 1 (Green)
      2-pair x 1 (Green)
      4-pair x 1 (Green)
      PoE Usage x 3 (Green)
      Data Rate10/100/1000Mbps
      Dimensions (W x D x H)170 x 100 x 40 mm
      Weight480g
      Unit Output VoltageDC 54V
      Power RequirementsAC 100-240V, 1.5A max.
      Power Consumption120 watts max.
      No. of devices that can be powered1
      Power over Ethernet
      PoE StandardIEEE 802.3at/bt Ultra PoE PSE
      PoE Power Output BudgetDC 54V / 95-watt PoE via 4-pair
      DC 54V / 30-watt PoE via 2-pair
      PoE Power OutputMax. 90W@1 m cable
      Max. 73W@100 m cable
      PoE Power Supply TypeEnd-span + Mid-span
      Power Pin AssignmentPair 1 End-span: 1/2 (-), 3/6 (+)
      Pair 2 Mid-span: 4/5 (+), 7/8 (-)
      Standards Conformance
      Standards ComplianceIEEE 802.3 10BASE-T Ethernet
      IEEE 802.3u 100BASE-TX Fast Ethernet
      IEEE 802.3ab 1000BASE-T Gigabit Ethernet
      IEEE 802.3bt 4-pair Power over Ethernet Type 4
      IEEE 802.3at Power over Ethernet Plus
      IEEE 802.3af Power over Ethernet
      Regulatory ComplianceFCC Part 15 Class A, CE
      Environment
      Operating Temperature0 ~ 50 degrees C
      Storage Temperature-10 ~ 70 degrees C
      Operating Humidity5 ~ 90%, relative humidity, non-condensing
      Storage Humidity5 ~ 90%, relative humidity, non-condensing
      Standard Accessories
      Package ContentsPOE-175-95
      User's manual
      Power cord
      Diğer Özellikler
      Stok KoduPL-POE-175-95
      MarkaPLANET
      Stok DurumuVar
      Garanti (Yıl)2
      4711605283670
