    Planet PL-XGS-6311-12X 12 Port 10Gbase SFP+ Managed Ethernet Switch

    Planet PL-XGS-6311-12X 12 Port 10Gbase SFP+ Managed Ethernet Switch Planet PL-XGS-6311-12X 12 Port 10Gbase SFP+ Managed Ethernet Switch
    Görsel 1
    Görsel 2
    Para_Puan : 129.472
    Fiyat:
    15.536,64 TL
    Havale / EFT:
    15.070,54 TL
    2.900,17 TL'den başlayan taksit seçenekleri için tıklayın.
    Aynı Gün Kargo Kargo Bedava

    Ürüne Oy Verin

    Satıcıya Danış

    Planet PL-XGS-6311-12X 12 Port 10Gbase SFP+ Managed Ethernet Switch


    Hardware Specifications
    SFP+ Slots12 10GBASE-SR/LR SFP+ interfaces (port-1 to port-12)
    Compatible with 1000BASE-SX/LX/BX SFP transceiver
    Console1 x RJ45-to-RS232 serial port (9600, 8, N, 1)
    CPUMIPS 800MHz
    RAM512Mbytes
    Flash Memory32Mbytes
    Dimensions (W x D x H)330 x 230 x 43.6 mm, 1U height
    Weight1988g
    Power ConsumptionMax. 16.4 watts/55.9 BTU (Power on without any connection)
    Max. 30.2 watts/102.9 BTU (Full loading)
    Power RequirementsAC 100~240V, 50/60Hz
    Fan2
    LEDSystem:
    ?PWR (Green), SYS (Green)
    Ports:
    ?10G LNK/ACT (Green)
    ?1G LNK/ACT (Amber)
    Switching Specifications
    Switch ArchitectureStore-and-forward
    Switch Fabric240Gbps/non-blocking
    Switch Throughput178.56Mpps
    Address Table32K MAC address table with auto learning function
    ARP Table8K
    Routing Table12K
    IP Interface1024
    ACL Table4K
    Shared Data Buffer16MB
    Flow ControlBack pressure for half duplex
    IEEE 802.3x pause frame for full duplex
    Jumbo Frame12KB
    IPv4 Layer 3 Functions
    IP Routing ProtocolStatic route
    RIPv1/v2
    OSPFv2
    Layer 3 ProtocolARP
    ARP Proxy
    IGMP Proxy
    IPv6 Layer 3 Functions
    OtherICMPv6,ND,DNSv6
    Layer 2 Function
    Port ConfigurationPort disable/enable
    Flow control disable/enable
    Bandwidth control on each port
    Port loopback detect
    Port StatusDisplay each port’s speed duplex mode, link status, flow control status and auto negotiation status
    VLAN802.1Q tagged based VLAN, up to 4K VLAN groups
    802.1ad Q-in-Q (VLAN stacking)
    GVRP for VLAN management
    Private VLAN Edge (PVE) supported
    Protocol-based VLAN
    MAC-based VLAN
    IP subnet VLAN
    Bandwidth ControlTX/RX/Both
    Link AggregationIEEE 802.3ad LACP/static trunk
    Supports 64 groups with 8 ports per trunk group
    QoS8 priority queues on all switch ports
    Supports strict priority and Weighted Round Robin (WRR) CoS policies
    Traffic classification:
    ?IEEE 802.1p CoS/ToS
    ?IPv4/IPv6 DSCP
    ?Port-based WRR
    MulticastIPv4 IGMP v1/v2/v3 snooping
    IPv4 Querier mode support
    IPv6 MLD v1/v2 snooping
    Multicast VLAN Register (MVR)
    Up to 1024
    Security Function
    Access Control ListSupports Standard and Expanded ACL
    IP-based ACL/MAC-based ACL
    Time-based ACL
    Up to 2K entries
    SecurityPort isolation
    Supports IP + MAC + port binding
    Identification and filtering of L2/L3/L4 based ACL
    Defend against DOS or TCP attacks
    Suppression of broadcast, multicast and unknown unicast packet
    DHCP Snooping, DHCP Option 82/43/60/61/67
    Command line authority control based on user levels
    AAATACACS+ and IPv4/IPv6 over RADIUS
    AuthenticationIEEE 802.1x port-based network access control
    Management Function
    System ConfigurationConsole, Telnet, Web browser, SNMP v1, v2c
    Secure Management InterfacesSSHv2, TLSv1.2, SNMPv3
    ManagementIPv4 and IPv6 dual stack management
    User IP security inspection for IPv4/IPv6 SNMP
    SNMP v1, v2c and v3
    SNMP MIB and TRAP
    SNMP RMON 1, 2, 3, 9 four groups
    IPv4/IPv6 FTP/TFTP
    IPv4/IPv6 NTP
    RADIUS authentication for IPv4/IPv6 Telnet user name and password
    IPv4/IPv6 SSH
    The right configuration for users to adopt RADIUS server’s shell management
    CLI, console, Telnet
    Security IP safety net management function: avoid unlawful landing at nonrestrictive area
    Syslog server for IPv4 and IPv6
    TACACS+
    PLANET Smart Discovery Utility
    SNMP MIBsRFC 1213 MIB-II
    RFC 1215 Internet Engineering Task Force
    RFC 1271 RMON
    RFC 1354 IP-Forwarding MIB
    RFC 1493 Bridge MIB
    RFC 1643 Ether-like MIB
    RFC 1907 SNMP v2
    RFC 2011 IP/ICMP MIB
    RFC 2012 TCP MIB
    RFC 2013 UDP MIB
    RFC 2096 IP forward MIB
    RFC 2233 if MIB
    RFC 2452 TCP6 MIB
    RFC 2454 UDP6 MIB
    RFC 2465 IPv6 MIB
    RFC 2466 ICMP6 MIB
    RFC 2573 SNMP v3 notify
    RFC 2574 SNMP v3 vacm
    RFC 2674 Bridge MIB Extensions (IEEE 802.1Q MIB)
    RFC 2674 Bridge MIB Extensions (IEEE 802.1P MIB)

    Diğer Özellikler
    Stok KoduPL-XGS-6311-12X
    MarkaPLANET
    Stok DurumuVar
    4711605287210
