    Qnap TS-1232PXU-RP Cortex 457 4GB DDR4 12x3.5 inch HDD 2xLAN 2XSFP Ağ Depolama NAS

    Görsel 1
    Görsel 2
    Para_Puan : 830.274
    99.632,84 TL
    Havale / EFT:
    96.444,59 TL
    Aynı Gün Kargo Sınırlı Sayıda Kargo Bedava

    Qnap TS-1232PXU-RP Cortex 457 4GB DDR4 12x3.5 inch HDD 2xLAN 2XSFP Ağ Depolama NAS


    • Download Datasheet
    CPUAnnapurnaLabs Alpine AL324 64-bit ARM® Cortex-A57 4-core 1.7GHz processor
    CPU Architecture64-bit ARM
    Floating Point Unit
    Encryption Engine
    System Memory4 GB UDIMM DDR4 (1 x 4 GB)
    Maximum Memory16 GB (1 x 16 GB)
    Memory Slot1 x UDIMM DDR4
    Flash Memory512 MB (Dual boot OS protection)
    Drive Bay12 x 3.5-inch SATA 6Gb/s, 3Gb/s
    Drive Compatibility3.5-inch bays:
    3.5-inch SATA hard disk drives
    2.5-inch SATA hard disk drives
    2.5-inch SATA solid state drives
    M.2 SlotOptional via a PCIe adapter
    SSD Cache Acceleration Support
    2.5 Gigabit Ethernet Port (2.5G/1G/100M)2 (2.5G/1G/100M/10M)
    10 Gigabit Ethernet Port2 x 10GbE SFP+
    Wake on LAN (WOL)
    Only the 2.5GbE port
    Jumbo Frame
    PCIe Slot1
    Slot 1: PCIe Gen 2 x2
    PCIe bandwidth limitations will restrict the NAS 10GbE performance.
    Card dimensions for PCIe slot?220 x 68.9x 18.76 mm / 8.67 x 2.71 x 0.74 inches.
    USB 3.2 Gen 1 port4
    Form Factor2U Rackmount
    LED IndicatorsHDD 1-12, Status, LAN, Storage expansion
    ButtonsPower, Reset
    Dimensions (HxWxD)88.6 × 432 × 511 mm
    Excludes ear hook and the protruding part of the Power Supply Unit.
    Weight (Net)12.94 kg
    Weight (Gross)14.94 kg
    Operating Temperature0 - 40 °C (32°F - 104°F)
    Storage Temperature-20 - 70°C (-4°F - 158°F)
    Relative Humidity5-95% RH non-condensing, wet bulb: 27?C (80.6?F)
    Power Supply Unit250W (x2) PSU, 100 - 240V
    Power Consumption: Operating Mode, Typical83.57 W
    Tested with drives fully populated.
    Fan2 x 70mm, 12VDC
    System WarningBuzzer
    Standard Warranty3
    Max. Number of Concurrent Connections (CIFS) - with Max. Memory700
    Diğer Özellikler
    Stok KoduTS-1232PXU-RP-4GB
    Stok DurumuVar
