DONANIM ÖZELLİKLERİ | |
---|---|
Arabirim | • 8× 10/100 Mbps 802.3af/at PoE+ Ports, 2× Gigabit RJ45 Ports, 1× Gigabit SFP Port • AUTO Negotiation • AUTO MDI/MDIX |
Ağ Medyası | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) • EIA/TIA-568 100Ω STP (maximum 100m) |
Fan Sayısı | Fanless |
Fiziksel Güvenlik Kilidi | Yes |
Harici Güç Kaynağı | External Power Adapter (Output: 53.5VDC / 2.43A) |
Paket Yönlendirme Hızı | 5.6544 Mpps |
PoE Portları (RJ45) | • Standard: 802.3 af/at compliant • PoE Ports: Ports 1–8 • Power Supply: 124 W |
MAC Adres Tablosu | 2K |
Jumbo Frame | 16 KB |
Switching Kapasitesi | 7.6 Gbps |
Boyutlar ( W X D X H ) | 8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm) |
Maks. Güç Tüketimi | • 5.95 W (220/50 Hz. no PD connected) • 140.92 W (220/50 Hz. with 124 W PD connected) |
Max Heat Dissipation | • 20.29 BTU/h (no PD connected) • 480.54 BTU/h (220/50 Hz. with 124 W PD connected) |
YAZILIM ÖZELLİKLERİ | |
---|---|
İletim Metodu | Store-And-Forward |
Gelişmiş Fonksiyonlar | • Compatible With IEEE 802.3af/at Compliant PDs • Extend Mode Button (Ports 1–4 and Ports 1–8, Up to 250 m PoE power supply and data transmission) • Isolation Mode Button (Ports 1–8) • PoE Auto Recovery Button (Ports 1–8) • Mac Address Auto-Learning and Auto-Aging • IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure for Half-Duplex Mode |
DİĞERLERİ | |
---|---|
Sertifika | FCC, CE, RoHS |
Paket İçeriği | • TL-SL1311MP • Power Adapter • Installation Guide |
Ortam | • Operating Temperature: 0–40 ? (32–104 ?) • Storage Temperature: -40–70 ? (-40–158 ?) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing |
Diğer Özellikler | |
---|---|
Stok Kodu | TL-SL1311MP |
Marka | TP-LINK |
Stok Durumu | Var |
